Specification
| Product Model | FT-NM-915Q5-420B |
| Product Specification | |
| 1、Electrical | |
| Frequency Range | 902～928MHz |
| V.S.W.R | ≤1.4 |
| Gain | 5DBi |
| Polarization | Vertical |
| F Beam-Width.H-Plan | 360° |
| F Beam-Width.E-Plan | 16° |
| Impedance | 50Ω |
| Max. Input Power (W) | 50 |
| Lightning Protection | DC Grounded |
| 2、Material & Specification | |
| Connector | N Male |
| Size | Φ20X420mm |
| Color | Black |
| Material | Fiberglass |
| Pole Diameter | Φ30-60(mm) |
| Rated Wind Velocity | -60m/s |
| Temperature Range | -40℃ to +85℃ |
| Substance Compliance | RoHS |
| Weight | 308g |
| Package Type | 50PCS |
