Specification
| Product Model | FT-NF-915D09-260 |
| Product Specification | |
| 1、Electrical | |
| Frequency Range | 902～928MHz |
| V.S.W.R | ≤1.4 |
| Gain | 9DBi |
| Polarization | RHCP |
| F Beam-Width.H-Plan | 60° |
| F Beam-Width.E-Plan | 50° |
| Impedance | 50Ω |
| Front to Back Ratio(db) | ≥25dB |
| Max. Input Power (W) | 100 |
| Lightning Protection | DC Grounded |
| 2、Material & Specification | |
| Connector | N Female |
| Size | 260X260X34mm |
| Color | White |
| Material | ABS |
| Pole Diameter | -Φ30-60(mm) |
| Rated Wind Velocity | -60m/s |
| Temperature Range | -40℃ to +85℃ |
| Substance Compliance | RoHS |
| Weight | 720g |
| Package Type | 50PCS |
Specialized in designing, manufacturing, and selling all kinds of RF Connectors, RF Adapters, Cable Assemblies and Antennas.
FUTAI HONGKONG CO.,LTD
